KATflow 230
Engineered for performance and convenience, this compact device delivers powerful functionality in a practical, portable form—perfect for professionals on the move and demanding tasks in any environment.
The KATflow 230 is easily portable but incorporates an advanced specification for situations which require comprehensive measurement features coupled with easy operation. The flowmeter has two measurement channels, which allow it to monitor two pipes simultaneously or to improve accuracy in non-ideal conditions. The KATflow 230 can also be supplied with a variety of options to meet the most diverse application requirements.
The choice of 4-20 mA, relay and open-collector outputs available on the KATflow 230 allow it to be used as a temporary replacement for existing in-line flowmeters when calibration is due. Moreover, the inclusion of PT100 temperature inputs enables the instrument to provide either temperature compensated flow data, or full energy measurement. This functionality can be further enhanced by using the innovative expansion capability which permits the flowmeter to perform dual-channel heat quantity measurements or to integrate alternative output options such as Modbus.
- Various input and output options for added flexibility
- PT100 inputs for heat quantity (energy) measurement
- Up to 100,000 measurement data logger and software for sampling and data transfer
- Stainless steel sensors, cable and connectors as standard
- Three different transport case options including special IP 67 version
- Standard and high temperature pipe wall thickness gauges available
- Pipe diameter range 10 mm to 6,500 mm
- Temperature range for sensors -30 °C to +250 °C (-22 °F to +482 °F)
- Robust IP 65 aluminium enclosure
- Selectable three-line LCD display and full keypad
- Battery life up to 24 hours with easily replaced battery cartridge
- Dual flow monitoring with sum, average, difference and maximum calculations
Building Services
- Single or dual-channel heat quantity measurement
- Efficiency monitoring of heat exchangers
- Pump testing and inspection
Water and Wastewater
- Drinking water and effluent measurements
- Dual-channel measurements on large pipes for increased accuracy
- Screened sludge monitoring
Manufacturing and Process
- Measurement of hydraulic oil
- Fuel consumption measurements
- Measurement of paint flows
Power Generation
- Measurement of cooling circuits
- Verification of main water inlets
- CHP monitoring (Combined Heat and Power)
Marine and Shipbuilding
- Heavy fuel oil measurements
- Balancing of hot water systems
- Monitoring of sea water inlets
General Industry
- CIP system testing
- In-line flowmeter performance verification
- Temporary replacement of conventional in-line flowmeters
