Clamp-on Ultrasonic Doppler Flow Monitor
KATFlow 10
The KATflow 10 is a simple ultrasonic clamp-on flow monitor, which provides an extremely cost-effective alternative to in-line flowmeters on effluent, wastewater and sludge applications. The KATflow 10 is used to monitor the flow of liquids containing higher levels of solids or entrained gas bubbles for measurements where a general flow indication is sufficient. The instrument is extremely simple to install and commission and is ideal for applications which demand good repeatability and reliable results.
The KATflow 10 applies a new measurement technique known as the Refracted Spread Spectrum Analysis, and requires liquids, which contain entrained solids, gases or turbulence in order to provide a measurement. The flow monitor is manufactured from 316 stainless steel and is available with 4-20 mA and volt free relay outputs. The KATflow 10 can also be configured using RS 232, RS 485 and Modbus using dedicated software.
Compact flowmeter for fixed installations, designed for pipe diameters from 30 to 350 mm. Mains powered with IP67-rated protection for reliable outdoor or industrial use. Offers standard process outputs and weighs just 1.5 kg for easy handling and integration.
- Small size
- Quick and simple installation
- No complicated process connections
- Low purchase costs
- Easy programming through dedicated software
- For acoustically conductive fluids with particle concentration > 200 ppm
- Pipe diameter range 30 mm to over 350 mm
- Temperature range -20 °C to +70 °C (-4 °F to +158 °F)
- Robust 316 stainless steel housing
- Velocity range 0.3 … 4 m/s
- Power supply 18 … 28 VDC
- Weight 1.5 kg
- Communication: 1 x Volt free relay, 1 x 4…20mA active output RS 232, RS 485 Modbus RTU
Water and Wastewater
- Wastewater Measurements
- Sludge monitoring
- Effluent measurements
- Pump protection
Food Production
- Metering food waste pipes
- High viscosity food production lines
Power Generation
- Feed flows to anaerobic digesters
General Industry
- Aerated Liquids
- Quarry slurries
- Activated Sludge
- Ash Slurries
- Paper Stock
- Paint
